Item specifics
  • Item Type: Blood Pressure
  • Brand Name: Hailicare
  • Material: ABS
  • Application: Finger
  • Model Number: 103Prince100BPro
  • Size: Prince100BPro
  • Commodity Quality Certification: CE
  • is_customized: Yes
Product Description





HealForce New LED Display Design oxymetre pulsioxmetro Fingertip Pulse Oximeter Spo2 PR monitor Blood Oxygen meter Monitor

Technical Specifications
A.  Power supply requirement:
      2 x LR03 (AAA) alkaline batteries
      Supply voltage: 3.0VDC
      Operating current: ≤40mA
B.  SpO2 Parameter Specifications
      Transducer: dual-wavelength LED sensor
      Measurement wavelength:
      Red light: 663 nm, Infrared light: 890 nm.
       Maximal optical output power: less than 1.5mW   maximum average
      Measuring range: 35~100%
      Measuring accuracy:
      Not greater than 3% for SpO2 range from 70% to 100%
C.  Pulse Rate Parameter Specifications
      Measuring range: 30bpm~240bpm
      Accuracy: ±2bpm or ±2% (whichever is greater)
D.  Perfusion Index(PI) Display
      Range: 0%~20%
E.  Preset over-limits
      SpO2 low limit: 90%
      Pulse Rate :   high limit: 120bpm
                             low limit: 50bpm
F.  Audible & visual alert function
     When measuring, if SpO2 value or pulse rate value exceeds the preset limit, the device      will alert automatically and the value which exceeds limit  will flash on the screen.
G. Environment requirement
    Operating Temperature:   5°C ~40°C
    Operating Humidity:   30%~80%
    Atmospheric pressure:    70kPa~106kPa
H. The performance under low perfusion condition
    The accuracy of SpO2 and PR measurement still meet the precision described above          when the modulation amplitude is as low as 0.6%.
I.   Resistance to interference of surrounding light:
     The difference between the SpO2 value measured in the condition of indoor natural             light and that of darkroom is less than ±1%.
J.  Resistance to 50Hz /60Hz interference:
     SpO2 and PR are precise which have been tested by BIO-TEK pulse oximeter                    simulator.
K.  Dimensions: 66 mm (L) × 36 mm (W) × 33 mm (H)
      For PC-60A & PC-60B series
      Dimensions: 60 mm (L) × 33mm (W) × 30 mm (H)
      For POD series
      Net Weight: 60g (including batteries)
L.  Classification
     The type of protection against electric shock: Internally powered equipment.
     The degree of protection against electric shock: Type BF applied parts.
     The degree of protection against harmful ingress of liquids:  Ordinary equipment                   without protection against ingress of water.
      Electro-Magnetic Compatibility: Group I, Class B

Accessories
A.  A lanyard
B.  A pouch
C.  A User Manual
D.  Quality Certificate

Note: batteries not included
